$14,294.77
In Stock
Advanced Switching Layer 3
Compliant Standards IEEE 802.1ab (LLDP), IEEE 802.1p, IEEE 802.1Q, IEEE 802.1s, IEEE 802.1x, IEEE 802.3ad (LACP), IEEE 802.3bt
Features Access Control List (ACL) support, Adaptive policy, Broadcast Storm Control, Cisco Discovery Protocol (CDP), Cisco StackPower technology, DHCP relay, DHCP server, DHCP snooping, DSCP to CoS Mutation, Dynamic ARP Inspection (DAI), Firmware upgradable, Hot swappable 3 fans, MAC Access Bypass (MAB), Network diagnostics, Per-VLAN Spanning Tree (PVST), Port mirroring, Protocol Independent Multicast (PIM), Push notification, Quality of Service (QoS), Rapid PVST (RPVST), Role-Based Access Control (RBAC), Sticky MAC, STP BPDU Guard, STP loop guard, STP Root Guard, Uni-Directional Link Detection (UDLD), Usage statistics, VLAN support, VLAN trunking, Zero-touch provisioning (ZTP).
Compliant Standards AN/NZS 60950.1, CAN/CSA-C22.2 No. 60950-1, CISPR 22 Class A, CISPR 24, CISPR 32 Class A, CNS 13438, EN 300 386 V1.6.1, EN 55022 Class A, EN 55032, EN 60950-1, EN 61000-3-2, EN 61000-3-3, EN55024, FCC CFR 47 Part 15 Class A, ICES-003 Class A, IEC 60950-1, KN32, KN35, RoHS, TCVN 7189 Class A, TCVN 7317, UL 60950-1, V-2/2015.04, V-3/2015.04, VCCI-CISPR 32 Class A
ENERGY STAR CertifiedNo
EPEAT CompliantNo
TCO CertifiedNo
Service & Support Details Limited warranty – advanced replacement – lifetime – response time: next business day
Limited Warranty Limited Lifetime
| MAC Address Table Size | 32000 entries |
|---|---|
| Manageable | Yes |
| Max Units In A Stack | 8 |
| PoE Budget | 560 watt |
| Ports | 24 |
| Power Over Ethernet (PoE) | UPOE |
| Product Type | Switch |
| Remote Management | DHCP, IPv4, IPv6, SNMP, Syslog |
| Routing Protocol | IGMP, MSTP, OSPFv2, RSTP, Static IP routing, STP, VRRP |
| Stackable | Stackable |
| Status Indicators | Status |
| Subcategory | Network hubs and switches |
| Switching Type | 10 Gigabit Ethernet |
| Expansion Slots | 1 (total) / 1 (free) x expansion slot |
| Interface Provided | 1 x management, 1 x USB Type A, 1 x USB Type B console, 2 x network stack device, 24 x 100/1000/2.5G/5G/10GBase-T RJ-45 UPOE - 60 W |
|---|---|
| Port Quantity | 24 |
| Port Type | 100/1000/2.5G/5G/10GBase-T (UPOE) |
| Frequency | 50 - 60 hertz |
|---|---|
| Hot-Plug | Hot-plug |
| Power Provided | 1100 watt |
| Power Supplies Installed | 1 |
| Power Supplies Installed | 2 |
| Redundant Power Supply | Optional |
| Required Voltage | AC 100-240 volt |
| 80 PLUS Certification | 80 PLUS Platinum |
| Built-in Devices | 3 x fans |
|---|---|
| Max Operating Temperature | 113 degree Fahrenheit |
| Max Storage Temperature | 158 degree Fahrenheit |
| Min Operating Temperature | 23 degree Fahrenheit |
| Min Storage Temperature | -4 degree Fahrenheit |
| MTBF | 214,760 Hours |
| Operating Humidity | 5 - 90% |
| Authentication Method | RADIUS |
|---|---|
| Capacity | Member ports per aggregated link: up to 8, QoS queues: 8, VLANs with trunking: 4094 |
| Device Type | Internal power supply |
| Packaged Quantity | 1 |
| Performance Forwarding rate | 476.19 Mpps, Stacking bandwidth: 480 Gbps, Switching capacity: 640 Gbps |
| Rack Mounting | KitIncluded |
| Height | 1.7 inch |
|---|---|
| Height (Rack Units) | 1 |
| Weight | 18.19 lbs |
| Width | 17.5 inch |
| Depth | 20.2 inch |
